CHANGZHOU UNITED WIN PACK CO.,LTD
| Place of Origin: | CHINA |
|---|---|
| Brand Name: | unitedwin |
| Model Number: | SYJ-800E |
| Minimum Order Quantity: | 1 set |
| Price: | USD |
| Delivery Time: | 3 months |
| Supply Ability: | 3 sets/ month |
| Diameter Of Unwinding Cloth: | ≤Ø1200mm | Max. Feeding Width: | 800mm |
|---|---|---|---|
| Model: | SYJ-800E | Max Feeding Width: | 800mm |
| Printing Speed: | 80-120m/min | Max Printing Area: | 650 Mm |
| Max Material Feeding: | 1200x820 Mm | Total Power: | 18kw |
| Dimensions: | 1600*3000*2500 | Automatic Grade: | Automatic |
| High Light: | 1200mm dia woven bag printing machine,pneumatic feeding woven bag printing machine |
||
Four/Five/Six/Seven/Eight Color Continuous Printing Machine for Woven Bag Roll to Roll
Functions of equipment
1,The machine uses pneumatic feeding fabric
2,The machine uses EPC
3,The machine uses Positive and negative one printing, 8+0,7+1,6+2,5+3,4+4 and so on
4,The machine uses Intelligent controls the length of bag, universal size ,any bag length changeable without changing the printing roller and gears
5,The machine uses PLC centralized control, user can use the touch screen to set the length of the bag, the version
6,The machine uses color code tracking, which is suitable for reverse printing color printing woven bag
7,The machine uses Horizontal 25mm, vertical 360 degrees electric checking version
8,The machine uses auto loading & cycling ink, auto ink mixture while stop
9,The machine uses automatic clutch imprint, stop and start no defictive goods
10,The machine uses automatic constant temperature controls double-sides drying
11,The machine uses the unwinder and winder are controlled by inverter
Our machine can offer you competitive price, easy operating, portable, labor-saving and easy production. The machine used the Latest Patented Technology and computer-controlled system, which is easy to control and use. Our machine don’t need to change the printing plate rollers for different bag length. The automatic control system could save the labor cost, improve product quality, and ensure production safety.
Specifications:
| Model | SYJ-800E |
| Diameter of Roller | ≤φ1500mm |
| Max feeding width | 800mm |
| Max printing width | 650mm |
| Machinery production capacity | 150m/min |
| Normal printing speed | 80-120m/min |
| Gas consumption | 1M3/min |
| Fan power | 10KW |
| Total power | 18KW |
| Dimensions | 16000*3000*2500mm |
Application:
This machines is special for printing woven bags. The color register can be adjusting positive rotation and clockwise 360,Without tum off the power. the speed is quick, the color printing is precise; simultaneously the big printing roller may carry on the crosswise adjustment, the adjustment quantity is 20mm by PLC instead of original circuit board control. It is steady in operation and speed changing, and can be easily operated. The character is evenly and clear. with few vulnerable part.
FAQ:
1.Could I have prices of your products?
Welcome. Pls feel free to send us an email here. You will get our reply in 24 hours
2. Can we print our logo/website/company name on products?
Yes, please advise the size and Pantone Code of the logo.
3. What's the lead time for regular order?
15-20 days for order quantity; depends on the season and quantity, usually less than 30 days.
4. Can I get a discount?
Yes, for the order quantity more than 2 pcs, please contact us to get the best price.
5. Do you have training?
Yes, we will send our technical manual & video
6.How to deal with broken parts?
we guarantee 1 year warranty free of charge.
7. How could you do after one year warranty period?
We also can-do service for you, but you need pay salary for our technicians 80USD/day for each person.
