CHANGZHOU UNITED WIN PACK CO.,LTD
| Place of Origin: | CHINA |
|---|---|
| Brand Name: | United Win |
| Model Number: | UW-M90*30-580 |
| Minimum Order Quantity: | 1 set |
| Price: | USD |
| Delivery Time: | 3 months |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 10sets/month |
| Name: | Monofilament Extruder | Application: | PET |
|---|---|---|---|
| Processing Type: | Extruding Machine | Product Tape: | Zipper Line |
| Mono Size: | 0.4-0.12mm | Screw Dia: | 90mm |
| Screw Speed: | 25-100rpm | Automatic: | Yes |
| Color: | According To The Customers' Require | Weight: | 32T |
| Highlight: | Zipper Pet Monofilament Extrusion Line,Pet Monofilament Extrusion Line 90mm Screw,Monofilament Extrusion Plant |
||
PET Zipper Filament Monofilament Machine Extruder Make zipper Line SJY-90*30-580
Round wire drawing production line is a self-designed product based on digesting and absorbing advanced technology at home and abroad and combined with the actual situation of China's plastic industry. The utility model has the advantages of reasonable design, simple structure, convenient maintenance, beautiful appearance, stable operation, sensitive and reliable control.
Equipped with electrical control system to drive cloth take-up device instead of mechanical system. It not only greatly reduced the amount of mechanical transmission devices, but also lowered the maintaining costs and consumptions of spare parts. The high-accuracy linear synchronism between cloth take-up and host machine, enables the control system more powerful.
Specification:
| Item | UW-M90*30-580 |
| Raw matrial | PET |
| Screw Dia. | Φ90mm |
| L/D | 30:1 |
| Screw&barrel | 38CrMoIA |
| Screw Rpm. | 25-100rpm |
| Meter pump | One set |
| Nozzle plate | One set |
| Hole no.s | 60 Holes |
| Drawing section | One |
| Fixing section | One or Two |
| winders | 156spindles |
| Winder size | As client requirement |
| Installing power | 265KW |
| Overall size (L×W×H) | 46000×2500×2300mm |
| Weight | 32T |
Application:
FAQ:
1. How long will your engineer reach our factory?
Within one week after everything ready (machine arrival your factory, non-woven material, power source, air compressor etc. Prepared)
2. How many days will you finish installing?
We will finish installation and training within 15 days.
3. What should we charge for your engineer?
You should charge for the cost of our engineer's air tickets, hotel, food, and also their salary 80USD one day per person.
4. How long is your machine's warranty period?
All our machine has one year guarantee for electricity parts and two years guarantee for mechanism, starting from finished installation.
5. How could you do if the parts broken within warranty?
We would express the free replacement parts during the warranty date
6. How could you do after one year warranty period?
We also can-do service for you, but you need pay salary for our technicians 80USD/day for each person.
7. What is your terms of payment ?
30% T/T in advance ,balance before shipment.
