CHANGZHOU UNITED WIN PACK CO.,LTD
| Place of Origin: | CHINA |
|---|---|
| Brand Name: | unitedwin |
| Model Number: | UW-J30 |
| Minimum Order Quantity: | 1 set |
| Price: | USD |
| Name: | Three Roller Surface Rewinding Machine | Model: | UW-J30-13 |
|---|---|---|---|
| Effective Width: | 1300mm | Max Unwinding Dia.(mm): | Ø800mm |
| Max Rewinding Dia.: | Ø200mm | Unwinding Tension Control: | 20kg Magnetic Powder |
| Total Speed: | 120(max) M/min | Total Power: | 5.5kw |
| Dimension (LxWxH): | 1950x2830x1315mm | Warranty: | 1 Year |
| Place Of Origin: | China | ||
| Highlight: | Adhesive Tape Rewinding Machine,Double Sided Adhesive Tape Rewinding Machine,Three Roller Surface Rewinding Machine |
||
Three Roller Surface Adhesive Tape Rewinding Machine For Double-sided Tape UW-J30-13
Features:
1. Three rollers surface driving solve effectively the problem of material stretching and crinkle.
2. Speed of pressure roller and driving roller can be adjusted to suit different materials.
3. Auto-labeling system is optional to suit different material and requirement of customers.
4. Equipped with sound insulating cover, effectively reduce noise to fit environment requirement.
5. The whole machine has high automatization and efficiecy, easy operation.
Technical parameters:
| Model | J30-13 | J30-16 |
| Effective Width (mm) | 1300 | 1600 |
| Max unwinding dia.(mm) | Ø800 | Ø800 |
| Max rewinding dia. (mm) | Ø200 | Ø200 |
| Unwinding tension control | 20kg magnetic powder | 20kg magnetic powder |
| Total speed (m/min) | 120(max) | 120(max) |
| Total power (kw) | 5.5 | 5.5 |
| Dimension (LxWxH) (mm) | 1950x2830x1315 | 1950x3130x1315 |
Application:
Suitable for set length rewinding of masking tape, double-sided tape, cloth tape, BOPP, PET etc.
Company Information:
FAQ:
1. Are you a factory?
Yes, our company was established in 1998. It is the only comprehensive manufacturing enterprise in China produce both tape and
tape machine.
2. Can I get some tape samples for testing before placing order?
Yes,we can provide you some free samples for your reference.
3. How long is the delivery time for your tape?
The first order is 15 days after deposit,then other orders are about 7-10 days after deposit.
4. How could I get the quotation?
Tape: Please let me know the specification(thickness,width,length),quantity,application and other requirements according to your
needs so that we can provide an accurate quotation.
Machine: please provide the type of machine required and other special requirements.
5. Do you control the items quality?
Each machine strictly tested one by one before shipping.
6. How long is the delivery time for your machine?
After deposit is about 30 days.
7. What is quality guarantee policy?
12 months guarantee for all goods from our company, but we do not accept any broken by man.
8. When we receive the box, find any items missing or defective, how should we do?
Please contact us ASAP, we will check and give you best solution soon.
